YDS113 Door Shoes Aluminum
Door Shoes
- Available Finishes: A, C, BL, DB, G, PB, LB, PW
- Width: 1-14/17” (46.3 mm)
- Height: 1-3/4” (44.1 mm)
- Function：Dustproof Insectproof Soundproof
- Overview
- Recommended Products
This kind of door bottom shoes is applied to the underside of the door to create a strong seal against smoke, fire, dust, drafts and light without compromising on the appearance of the door. The aluminum track is fitted with a 0.5" (H) fingered vinyl seal and can be applied to doors with a minimum thickness of 1.825". Available in various finishes to coordinate with door color and length is custom cut to size.
Retainer Material |
Aluminum |
Temperature Range |
-4°F to 122°F |
Door Type |
Wooden Door, Metal Door |
Seal Type |
DVinyl Rubber Seal |
Mounting |
Door Shoe Mount |
Seal Height |
1/2" Height |
Total Height |
1-3/4" Height |
Additional Dimensions |
Door seal is 1-14/17" thick |
Length |
Standard 36", 48"; Custom Cut to Size |
Installation |
Drill holes are provided |
