ES006 Satin Stainless Steel Surface Mounted Electric Strike for Rim Exit Device Lock Cylinders
Electric Strike
-Material：Stainless Steel
-Voltage：12VDC/24VDC
-Usage：Door
-OEM：Available
- Overview
- Recommended Products
MEIHE’s ELECTRIC STRIKE portfolio includes RIM EXIT and UNIVERSAL CYLINDRICAL STRIKES for access control applications.
The RIM EXIT STRIKE is designed specifically for rim exit devices. This strike is completely surface mounted, which eliminates the need to cut into the door frame.
The UNIVERSAL CYLINDRICAL STRIKE provides controlled access and security for egress and ingress applications where code compliance and safety are paramount.
Modular Faceplate Options |
124L x 43W x 32H(mm) |
|
Three modular faceplates for the most common door types: hollow metal, aluminum and wood |
500kg |
|
Configurable |
DC 12V/DC 24V |
|
The non-handed fully reversible design is field selectable to 12 or 24 VDC and field reversible with a fail-safe or fail-secure mode |
12V/320mA(±10%)；24V/160mA(±10%) |
|
Durable |
Built-out MOV |
|
Factory tested to 1,000,000 cycles |
Door status Output,NO/NC/COM |
|
